While Nav is flashing, press the AUTO key to engage Auto mode under navigator control, otherwise the pilot
will return to its previous setting.
If the Bearing to Waypoint is within 20º of your heading and there is less than 0.05 nautical miles Cross Track
Error, the Pilot will immediately engage Auto mode under Navigator course control.
Bearing and Cross Track Error can be viewed in the Information display.
The Pilot will not engage Navigator Control immediately if the Bearing to Waypoint is greater than
20º of your heading (more than 0.05 nautical miles Cross Track Error) as this would cause a
sharp turn.
In this instance, the press of the AUTO key displays the BWP (Bearing to
bwp 145
The next press of the AUTO key displays the XTE (Cross Track Error).
xte <0.14
This example shows
xte 0.02>
xte 0.00
The third press of the key will engage the autopilot and is likely to cause a sharp turn.
It would be safer to manually steer closer to the course.
Once the Bearing to Next Waypoint and Cross Track Error are at an acceptable value press the AUTO key

to engage Navigator control.

Once the Pilot reaches the waypoint, the Navigator will send it a new Course to steer.
If Automatic Waypoint Sequence is selected, the Pilot will flash the bearing to next waypoint, for 7 seconds,
but turn onto it automatically after the first 2 seconds.
If Manual Waypoint Acceptance is selected, the Pilot will scroll the message n n e e w w w w p p t t p p r r e e s s s s a a u u t t o o for 10
seconds. The vessel will not turn onto the new course unless the AUTO key is pressed.
If the AUTO key has NOT been pressed, after 10 seconds the Pilot will switch to Compass control and con-
tinue on its present heading until Nav is re-selected or new instructions are received.

Navigator errors

If the Pilot is not receiving navigator data, this message will appear. Navigator
no nav
This indicates that no Cross Track Error information is being received from the
no xte
present heading and will not accept any furt-
the Navigator until the error clears.
If the Pilot receives an error message from the navigator when Auto mode is
navg err
NAVIGATOR ALARM:
48
COURSE CONTROL
Waypoint).
The number displayed is the cross track error in one hundredth's of a mile.
This example shows 0.02 miles Starboard (right) of the track.
This example shows that the pilot is on track.
cannot be selected. Check the cable, connections and message for-
mat.
Pilot will display a fault
If the alarm clears, the Pilot will accept data again and Navigator control can
resume. If the fault condition remains, turn back to Compass control, or
manually steer the vessel.
will display this message and remain in Standby mode.
The arrow indicates if the error is to Port or Starboard.
0.14 miles Port (left) of the track.
In the event of a navigator error or fault condition, the
message, hold the vessel on its
c o n t r o l
Navigator.
her course changes from
selected it
