Using the Dockside and Sea Trials settings

Having completed the mechanical installation and wiring of the system, the next step is to configure the Pilot
for the characteristics of the boat.
In order to use the pilot successfully, it is mandatory that you carry out the Boat Type and the Rudder
Settings Routine.
Press and hold the INFO and MODE keys until d d o o c c k k s s i i d d e e -[ [ < < ] ] / / s s e e a a t t r r i i a a l l -[ [ > > ] ] is displayed.
Press the key to select the Dockside settings menu.
Press the key to select the Sea Trial settings menu.
Using the settings menus
The settings use self prompting, scrolling messages, giving details on how to change the setting or to skip
to the next option:
The setting
Do not engage Auto mode until the Dockside Settings have been completed.
To exit, at any time, press and hold the INFO and MODE keys.
To save any changed settings, turn the Pilot OFF by pressing and holding the AUTO key.

Dockside Settings

Installation step summary:

1. Powering up for the first time.

2. Setting the Rudder Feedback type.

3. Setting boat type.
4. Rudder settings routine.
5. Aligning the compass.
6. Checking the settings.
1. Powering up for the first time
Ensure that all units are installed correctly, that the correct size fuses or circuit breakers are fitted and that
the ship's batteries are adequately charged. Check that all the system connections are correctly made and
return the rudder to the midships position before the power is applied.
Switch the Pilot system supply on (both Heavy Duty and Light Duty Supplies).
If the pilot starts to move the rudder, switch off at once and re-check the connections.
Press the AUTO key. If all is correct the Pilot displays a startup sequence finishing with a heading display,
which may not be accurate at this stage.
2. Setting the Rudder Feedback type.
Im Auslieferungszustand ist das System auf den optional erhältlichen Ruderlagegeber N03 220 401 einge-
stellt (Signalverstärkung eingeschaltet).
Ist der Linearantrieb X10.719/002/028 installiert, muss die Signalverstärkung ausgeschaltet werden. Bitte
beachten Sie den Abschnitt "Signalverstärkung Ruderlagegeber" auf S.xx.
With the amplification correct, set the rudder to midships, if the Rudder Position display is 5 degrees or less,
it will be corrected during the rudder settings routine. If over 5 degrees, mechanically re-adjust the Rudder
SETTINGS
set b b oat t t ype / / t t o c c hange- [ [ >] / / s s kip- [ [ mode]
To change the setting press this key
To skip to the next setting, press this key
53
