Components in Detail: Mounting Materials – Screws – Washers – Nuts – Hexagon Socket
M5 Washers
Mounting of:
starting mount – straight mandrel with stylus stopper -
multi-mandrel – arc mandrel – fl ex mandrel – 45° + 90° mandrels
Rulers – Angle rulers
M4x10 Hexagon Socket
Angle adjustment for:
45° + 90° mandrels
M3x40 Stylus
Replacement for:
straight mandrel with stylus stopper
M3 Hexagon Socket Key
Angle adjustment for:
45° + 90° mandrels
