5.17 Change menu code

CHANGE MENU CODE
select

5.18 Change language

select
Language options: NL, EN, DE, FR, PL, RO.

5.19 ModBus

select
Slave ID: adjustable 1 - 247
Factory setting: 1
Start bit, stop bit, parity and baud rate can be set via Ethernet.
After changing the slave ID the Pintherm Mistral restarts automatically.
Reset the overtime timer and/or continuous ventilation functions if necessary.

5.20 Ethernet Info

ETHERNET INFO
select
Display set IP address.
14
OK
CHANGE LANGUAGE
MODBUS SETTINGS
IP ADDRESS
192.168.001.100
OK
SELECT NEW CODE
1000
changes the
flashing digit
to go one digit up
New menu code
SELECT LANGUAGE
ENGLISH
OK
select the desired
language
MODBUS SETTINGS
001
OK
changes the
flashing digit
to go one digit up
MAC ADDRESS
5410EC220037
OK
OK
back to the
menu
OK
back to the
menu
OK
back to the
menu
OK
back to the
menu
