ABB AM 110 Betriebsanleitung

AM 110
1SFC101024M5501, 1(2), ed.5, November 2015
Contactors
Schütze
Contacteurs
Kontaktorer
Contattori
Contactores
Kontaktori
A 1
A 2
o 6,2
6 78 6
Pos. 2
Pos. 4
Pos. 1
According to UL 508:
Use wire Cu 75 C only.
Enclosure with min. dimension 24 by 20 by 10 inches should be used.
A1
A2
AM 110 -30-22
A1 A2
1L1 3L2 5L3
13 21 31 43
NO NC NC NO
NO NC NC NO
14 22 32 44
2T1 4T2 6T3
A1 1L1 3L2 5L3 13 21
NO NC NC
NO NC NC
A2 2T1 4T2 6T3 14 22
A 1
2,4 Nm - 21 lb.in
Pos. 3
M 8 4 mm
8 N.m - 71 lb.in
ø 5 Pozidriv N 2
M 3,5
1 N.m
Operating instructions
Betriebsanleitung
Notice d'instructions
Instruktion
Instruzioni techniche
IInstrucciones de empleo
Ohje
A1
A2
31 43
NO
NO
32 44
A 2
Pos. 5
A
A
OFF
43X
-
ON
35X
+
Y1
Impulse
Pushbuttons
UL Interrupting ratings
V AC kA
Protection
480 65
250 A
listed MCCB
600 25
250 A listed K5 or
600 10
RK 5 fuse or 250 A
listed MCCB
600 65
200 A listed class J fuse
Pos. 6
2 2
1 x 10 mm - 1 x 70 mm
2 2
2 x 6 mm - 2 x 35 mm
AWG 6 - AWG 2 / 0
+2
A) min 20 -0 mm
2 2
2 x 1 mm - 2 x 2,5 mm
2 2
2 x 0,75 mm - 2 x 2,5 mm
/ > 3,5 mm, L < 8 mm
K1
OFF
ON
Contactor
Relay
14
