The PS-10 230 is a thermostatic valve controller dedicated for underfloor heating system. Is equipped with:
• 9 voltage outputs (8 outputs dedicated to support thermostatic actuators and 1 output dedicated as pump)
• 1 voltage-free contact
• 2 Two-state inputs
The operating conditions of individual devices connected to the controller are programmed in the Sinum Central device. It is designed to be mounted on
a DIN rail. It communicates with the Sinum central device using radio signal.
- Power supply diode
- Manual mode diode
- Current status of the voltage-free output (ON/OFF)
- Communication
1-8 - Current status of the voltage output (ON/OFF)
In order to switch to the manual operation mode, press the manual operation button 1 . The registration button 2 is used to switch
between the controlled outputs in the manual mode. Using the button 1
(ON / OFF) - if the process has been successful, it is confirmed by a light signal from the LED labelled 1-8. When the manual mode is on, it is impossible
to control the contact via the website or the application. To disable the manual mode, press the button 1 again and hold it for 1-2 seconds. Once the
manual mode has been switched off, all the output status LEDs go off and resume the state set in the Sinum application.
When registering the device, it is recommended to use the heating creator. To run the creator, enter the address of the Sinum Central device in the
browser and log in to the device. In the main panel, click the Settings > System > Heating creator and after starting it, add the device by clicking the
registration button 2 at the right moment. Then follow the creator to create virtual thermostats, among other things.
The device can be registered also by going to Settings > Devices > SBUS Devices > + , then briefly press the registration button 2 on the device.
Each two-state input and voltage output will be added separately, in addition, virtual thermostats must be created and assigned to the appropriate room.

Technical data

Power supply
Max. power consumption
Operation temperature
Pump max. output load
Rated load of the voltage-free contact
Operation frequency
Max. transmission power
* AC1 load category: single-phase, resistive or slightly inductive AC load
** DC1 load category: direct current, resistive or slightly inductive load.
TECH Controllers is not responsible for any damages resulting from improper use of the system.
The range depends on the conditions in which the device is used and the structure and materials
used in the object construction. The manufacturer reserves the right to improve devices, update
software and related documentation. The graphics are provided for illustration purposes only and
may differ slightly from the actual look. The diagrams serve as examples. All changes are updated
on an ongoing basis on the manufacturer's website.
Before using the device for the first time, read the following regulations carefully. Not obeying these
instructions may lead to personal injuries or controller damage. The device should be installed
by a qualified person. It is not intended to be operated by children. It is a live electrical device.
Make sure the device is disconnected from the mains before performing any activities involving
the power supply (plugging cables, installing the device etc.). The device is not water resistant.
Description

Manual mode

How to register the device in the sinum system
230V ±10% /50Hz
4W
5°C ÷ 50°C
0,5A
230V AC / 0,5A (AC1) *
24V DC / 0,5A (DC1) **
868 MHz
25 mW
Notes
1 - Manual operation button
2 - Registration button
3 - Voltage-free contact output
4 - Voltage outputs
5 - Power supply
6 - Two-state inputs
(pressing it once), the user forces a change of the status

EU Declaration of conformity

Tech Sterowniki II Sp. z o.o. , ul. Biała Droga 34, Wieprz (34-122)
Hereby, we declare under our sole responsibility that
the thermostatic valve controller PS-10 230
is compliant with Directive 2014/53/EU.
Wieprz, 01.07.2023
The full text of the EU declaration of conformity and the user manual are
available after scanning the QR code or at
www.tech-controllers.com/manuals
