Expolite LED FRESNEL MINI Bedienungsanleitung Seite 20

CURVE DIMMING
20
GERÄTEEINSTELLUNGEN
3.4
SET Menu allows the user to adjust the fixtures settings.
KEY setting if ON requires Password to menu after lock. Password
is UP-DOWN-UP-DOWN Enter
DIMX allows to select the dimmingspeed. If OFF will dim instant,
otherwise will dim with delay. DIM4 is longest delay.
CURV selects the dimming curve as shown on the picture below
PERF setting will set performance according to noiselevel of the
fixture. LIVE will balance Noise and Output to acceptable level for
Livestage. STDO will take care for low noiselevel and reduce out-
put to control termal conditions. POWR will force maximum Output
by allowing full noiselevel
SLCK Settinglock will ask for Password to enter Settings. Pass-
word is UP-DOWN-UP-DOWN Enter
PERS Menu will set the Personality of the fixture as shown in
DMX-Charts.
DERR selects the fixtures respond on DMX-Error. Select Save for
holding the last value or Black to blackout.
REST will reset the fixture to standrd settings
MCON allows to select the Master-Control setting. The fixture can
send the Mastervalue to connected fixtures or not.
1: OFF
2: CV1
3: CV3
4: CV4
