DIMMER MANUELL
3.3
DIM Menu allows to control the intensity of the fixtures brightness
manually by using the UP/DOWN keys.
NOTE: WHEN THE FIXTURE IS SET TO MASTER MAST IN MA-
NUEL-CONTROL MCO, IT WILLSEND THE DIM VALUES TO ALL
CONNECTED SLAVE FIXTURES. WHEN DMX DATA IS RECEIVED,
IT WILL AUTOMATICALLY RETURN TO MAIN MENU AFTER 2
MINUTES WITHOUT KEY OPERATION.
MENU
DIM
RUN MODE
3.4
Enter the RUN MODE mode to set working mode.
DMX mode is for using the DMX512 controller to control the fixtures.
SLAVE mode is for Master -- Slave operation.
MENU
RUN MODE
DMX512 SETTINGS
3.5
Enter the ADDRESS menu to set the DMX ADDRESS.
MENU
ADRESS
D. (0-100)
DMX
SLAVE
0-512
