3.0 Product Assembly

3.1 Folding the Drone

1. Unfold the arms in the direction
of the arrow

3.2 Propeller Installation

Detaching the propellers
1
2
Remove the screws and the holder in the
direction of the arrow, and then detach
the propellers.
A
B
Note:
!
1. Please make sure that the propellers are installed in the correct position. If the
installation is incorrect, the drone will not be able to fly normally.
2. Since the propellers are thin, please be careful when installing them in case of
accidental scratches.
3. Please use the propellers provided by our manufacturer.
4. The propellers are consumables, if necessary, please purchase additional accessories.
2. Fold the arms in the direction of the arrow
1
3
Place the propellers on the arm of the
drone in the direction of the arrow,
place the holder then tighten the screws.
B
Referring to the figure below, install
the label "A" propeller and label "B"
propeller in the corresponding
positions, and use a screwdriver to
tighten the screws.
A
Installing the propellers
3
2
6
