BD Sensors LPT 200 Betriebsanleitung Seite 32

Reverse polarity protection
Mechanical stability
Vibration
Shock
Materials
Pressure port / flange
standard stainless steel 316 / 1.4401
Diaphragm
standard
option
Manufacturing label
Housing
standard option aluminum die cast with epoxy painting (blue)
Filling fluids
standard Silicon oil (-40...125°C)
Miscellaneous
Display (optionally)
configuration
Mounting bracket (optionally)
Ingress protection
Installation position
Weight
Current consumption
CE-conformity
Connections
Electrical connection
Process connections
standard
option
≤ 2,5 bar
1
only for P
N
no damage, but also no function
5 g RMS (25 ... 2000 Hz)
100 g / 1 ms
stainless steel 316L / 1.4404
®
Hastelloy C-276
stainless steel 316 / 1.4401
stainless steel 304 / 1.4301
others: on request
Type : LCD
Lines : 2
Digits : 8
: 0...100%
Bargraph
rotatability : yes, 90°-steps and / or by turn of the electronic case
- offset / span local via 2 buttons
- local configuration with an optional display
- complete configuration via HART
material CF8M or stainless steel 304 / 1.4401
IP 67
any
ca. 1.6 kg
approx. 23 mA
EMV Directive: 2004/108/EC
- terminal clamps in clamping chamber (for cable-Ø max.2.5 mm²)
½ " NPT IG
½ " NPT AG; ¼" NPT AG; M20x1,5 IG; G ½" IG;
vacuum connection DIN 28403KF16/ISO 2861
according to DIN EN 60068-2-6
according to DIN EN 60068-2-27
®
1
EN
others: on request
others: on request
others: on request
others: on request
