Contents
1 Introduction ............................................. 12
Product features ....................................... 12
2 Safety Instructions ................................. 13
3 Operating Determinations ..................... 14
4 Operating Elements and Connections . 15
Front panel................................................ 15
Rear panel ................................................ 16
5 Setup ........................................................ 17
Installation ................................................. 17
Cable connections .................................... 17
Powering up .............................................. 17
6 Operation ................................................. 18
Basic adjustment of the input channels .... 18
Basic adjustment of the output channels .. 18
7 Cleaning and Maintenance .................... 19
8 Technical Specifications ........................ 19
For product updates, documentation, software and
support please visit www.omnitronic.de. You can find
the latest version of this user manual in the product's
download section.
© 2023 OMNITRONIC. All rights reserved.
No part of this document may be reproduced in any
form without the written permission of the copyright
owner. The contents of this document are subject to
revision without notice due to continued progress in
methodology, design, and manufacturing.
All trademarks mentioned herein are the property of
their respective owners.
D00147450, Version 1.0, Stand 26/04/2023

1 Introduction

Welcome to Omnitronic! Thank you for choosing
one of our products.
This user manual will show you how to install and
operate the mixer. Users of this product are
recommended to carefully read all warnings in this
manual and on the unit in order to protect yourself
and others from damage.
Please save this document for future needs and
pass it on to further owners.
This user manual is valid for item number:
10007103. Please save this document for future
needs and pass it on to further owners.

Product features

• 5 input channels with recessed gain controls on
the rear panel, signal LED and super smooth
dual-rail channel faders
• 2 separate microphone channels with level
control, 3-way equalizer and talkover button
• Talkover level and response time adjustable
• Prefader listening (CUE) to the stereo input
channels via adjustable headphone output
• 1 additional line input with level control on the
front panel
• 2 adjustable master outputs with 3-way
equalizer and 10-digit stereo LED level meter
• 1 adjustable booth output with mono/stereo
selector switch
• 2 record outputs (independent of the master
channels) with on/off switch for microphone
signals
• 9 line inputs and 2 line/phono inputs via RCA
jacks
• 2 microphone inputs via combo jacks (XLR/
6.3 mm)
• 2 master outputs (optionally XLR/RCA), 1 booth
and 2 record outputs via RCA jacks
• 19" dimensions for rack installation, 2 U
12 • EN
