17 Technical Information

Controller Specifications

Controller Specifications

Tab. 1
Input:
- Voltage
- Power
Output:
- Voltage
- Frequency
-
Fuse
Operating temperature
Storage temperature
Weight
176/208
24 Vdc ±10 %
with 2 Vpp max ripple 110 W max.
64 Vac nominal ±10 %,
3-phase
1350 Hz, ±2 %
Power
Ramp up 80 W maximum
Normal 55 W maximum
T 5A 250 V 5x20 mm
0 °C to + 40 °C
-20 °C to + 70 °C
0.5 Kg (1.1 Ibs)
Turbo-V 81 PCB 24 Vdc Controller User Manual / 87-900-121-01 (D)
