INSTALLATION
WARNING! Risk of injury caused by falling objects
Devices in overhead installations may cause severe injuries when crashing down. Make sure that the
device is installed securely and cannot fall down. The installation must be carried out by a specialist who
is familiar with the hazards and the relevant regulations.
The device may be placed on the floor by unfolding the brackets or fastened to a truss or similar rigging structure.
The device must never be fixed swinging freely in the room.
1
The rigging structure must support at least 10 times the weight of all fixtures to be installed on it.
2
Block access below the work area and work from a stable
platform when installing the device.
3
Use rigging hardware that is compatible with the structure and
capable of bearing the weight of the device. Please refer to the
"Accessories" section for a list of suitable rigging hardware.
4
Secure the device with a safety bond or other secondary
attachment.
This
sufficiently dimensioned in accordance with the latest industrial
safety regulations and constructed in a way that no part of the
installation can fall down if the main attachment fails. An
appropriate eyelet is mounted on the device for fixation of the
safety bond. Fasten the safety bond in such a way that, in the
event of a fall, the maximum drop distance of the device will not
exceed 20 cm.
5
To align the device, release the fixation screws at the mounting
bracket, adjust the desired inclination angle and tighten the
fixation screws.
6
After installation, the device requires inspections periodically to
prevent the possibility of corrosion, deformation and looseness.
Changing the beam angle
With the delivery of the device you will receive a frost filter, with which the beam angle can be changed from 20° to
approx. 30°. If you want to change the beam angle of the device, simply attach the frost filter with magnetic
attachment in front of the lens of the device.
POWER SUPPLY
The device uses an auto-range power supply that accepts input voltages between 100 und 240 volts.
1
Connect the device via the mains cable to a grounded mains socket. Thus the unit is switched on.
2
To switch off the unit, disconnect the power plug.
secondary
safety
attachment
must
be
14/16
00145587, Version 1.0
