Fail Safe function setting

1. Set the TH, ST switches to the normal position.
2. Turn on the transmitter and receiver.
3. Press the F/S SET button, the LED on the receiver should start
flashing rapidly.
4. Put the throttle trigger at the brake position, press the F/S SET
button, the LED should become solid.
5. For electric model, put the throttle trigger at the stop position
when you are making the setting.

Binding the transmitter and receiver

1. Turn on the receiver power. Press the SW
switch. The receiver's LED should start
flashing.
AttENtION
Keep the transmitter and receiver not over 40 cm
apart when setting and binding.

Specifications

transmitter
receiver
It is CARSON's policy that we strive to improve the quality of our products. Therefore CARSON may alter specifications of our products at
any time without any notice.
Reflex Wheel Pro3:
As soon as the receiver/transmitter signal is interrupted, the
receiver switches to the default throttle failsafe setting.
Reflex Wheel Pro3 BEC:
The Reflex Wheel Pro2 is fitted with the „Failsafe pro +" system. This
system also has integrated low voltage protection. As soon as the
voltage is too low for safe operation, the receiver also switches to
the default throttle failsafe setting.
2. Turn on the
transmitter.
During the binding process no other transmit-
ter should be operated in the vicinity at the
same time!
Frequency 2.4 GHz
Power supply DC 4.8 - 6 V=
Power Supply DC 4.8~6.0 V (Battery box or via BEC-system from driving battery by Version
PRO3)
3. When the LED on the receiver becomes
solid, the binding process is completed.
