Function Version Reflex Wheel Pro3 - Carson REFLEX WHEEL PRO 3 Betriebsanleitung

Function Version REFLEX WHEEL PRo3

Power
ST trim
ST-D/R
TH trim
TH-D/R
Steering
wheel
Bat box
REflEx WHEEl PRO3 VERSION
WITHOUT BEC
Failsafe Set
REflEx WHEEl PRO3 VERSION
WITH BEC
Failsafe Pro + Set
Switch
Switch
Status LED
Servo reverse switch
Throttle trigger
Switch for Channel 3
Charger
Grip handle
Connectors
1. Steering servo (CH1)
2. Throttle servo (CH2)
3. CH3 servo (CH3)
4. CH4 servo (CH4)
B/C: Power connector
Connectors
1. Steering servo (CH1)
2. Throttle servo (CH2)
3. CH3 servo (CH3)
4. CH4 servo (CH4)
5. CH5 servo (CH5)
BEC: Power connector for BEC
33
