Transmitter Handling

A. throttLe trigger
Forward/
Speed up
Neutral
c. trim
ST trim left
ST trim right
TH trim front
TH trim back
reSet / reStoring the fActory SettingS (onLy for Lcd VerSion)
30
Brake/
Speed down
Left
B. Steering WheeL
Neutral
throttle trim:
Trim the throttle servo slightly when the trigger is at the neutral
position.
Steering trim:
If the front wheels do not align straight, use the steering trim to
adjust.
1St Step
delete all values saved in memory (trim/epa/exp):
• Switch on the transmitter.
• Press and hold the RESET button (with a pointed implement).
• A double peep will sound.
• Now release the reset button and switch the transmitter on
again. All done!!
2nd Step
recalibrate the control travels:
• Switch off the transmitter.
• Press and hold the RESET button (with a pointed implement) and
switch on the transmitter. The LCD screen is blank.
• Now release the reset button.
• The screen is back to normal and the calibration program has
been started.
• Now move the accelerator lever all the way forwards and then all
the way backwards. Then turn the steering wheel all the way to
the left and then all the way to the right.
• Now switch off the transmitter. Calibration is now complete. All
done!!
1. Push the trigger
forward to slow down
or brake.
2. Pull the trigger back-
ward to accelerate.
Right
