For operation, the transmitter requires 4 AA batteries or rechargea-
ble batteries or the appropriate LiPo power pack.
Once you switch on the On/Off switch, the transmitter is ready for
use.
After the transmitter has been switched on, the battery voltage will
appear in "V" on the LCD display and, below it, the model name/
number last selected will be displayed.
Settings are changed by means of the "SEL", "CH", "+" and "-"
buttons.
1. Press +/- to select the desired model. You have the choice of
15 memory spaces. The model number and model name are
indicated on the LCD display.
2. Press "SET" to take you to the desired setting. The following
functions are available for selection:
a) "reV" setting (reverse direction of servo rotation)
Press the "CH" button and choose between ST, TH or 3CH.
Press +/- for normal or reverse.
b) "epA" setting (servo travel limiter)
Press the "CH" button and choose between TH or ST. To
select the direction of rotation, the throttle must be to
the front or back with TH, and the steering wheel must be
moved left or right with ST. The display shows LFU for left
and forwards and RBU for right and brake. The desired value
can be set between 0 and 120% by means of +/-.
c) ABS setting (anti-blocking system)
Press +/- for ABS on or ABS off.
d) eXp setting (exponential)
Press the "CH" button and choose between ST (steering), FW
(forwards) and BK (brake). The desired exponential value can
be set between -100% and 100% by means of +/-.
e) modeL nAme (enter name of model)
Press the CH button until you come to the model name
setting. The characters 0 - 9 and A - Z can be entered by
means of +/-.
32
3. ST-TRIM (trimming the steering)
Press TRIM-ST+ or TRIM-ST- to change the neutral position
of the steering servo. It may be adjusted from 0 - 100% right
to 0 - 100% left.
TH-TRIMM (trimming the throttle)
Press TRIM-TH+ or TRIM-TH- to change the neutral position
of the throttle servo.
It may be adjusted from 0 -100% throttle to 0 - 100% brake.
TRIM 3C + 4C for channels 3 and 4.
4. D/R ST setting (dual rate steering)
Dual rate increases or reduces the servo travel in relation to
the travel of the steering wheel/ throttle proportionally over
the entire servo path.
Press D/R ST+ or D/R ST- to change the dual rate setting of
the steering.
A value between 0 and100% may be set.
5. D/R TH setting (dual rate throttle)
Press D/R TH+ or D/R TH- to change the dual rate setting of
the throttle.
A value between 0 and 100% may be set.
6. To close the settings, press the SEL button until the battery
display reappears.
Then the newly entered values are automatically saved.
