Function Version REFLEX WHEEL PRo3 LCD

LCD Display
Power
ST trim left
ST trim right
TH trim front
TH trim back
Steering
wheel
Bat box
REflEx WHEEl PRO3 VERSION
WITHOUT BEC
Failsafe Set
REflEx WHEEl PRO3 VERSION
WITH BEC
Failsafe Pro + Set
Switch
Switch
Status LED
Throttle trigger LCD Display
Switch for Channel 3
SEL/CH
Charger
button
Grip handle
ST D/R
button
Connectors
1. Steering servo (CH1)
2. Throttle servo (CH2)
3. CH3 servo (CH3)
4. CH4 servo (CH4)
B/C: Power connector
Connectors
1. Steering servo (CH1)
2. Throttle servo (CH2)
3. CH3 servo (CH3)
4. CH4 servo (CH4)
5. CH5 servo (CH5)
BEC: Power connector for BEC
+/- button
TH D/R
button
29
