9. Specifications
Measurement range :
Max error (0,01 mm resolution) :
Max error (0,001 mm resolution) :
Repeatability :
Weight :
Measurement force (standard) :
Max, speed of travel :
No, of measurements/ sec :
Measurement unit :
Maximum Preset (0,01 mm resolution) :
Maximum Preset (0,001 mm resolution) :
Measurement system :
Power :
Average consumption :
Average battery life :
Data output :
Working temperature (storage) :
Electromagnetic compatibility :
IP rating (in accordance with IEC60529) :
Fixing and space envelope :
01930320 (0,01 mm)
measurement : 10 mes/s
metric/english (Inch)
±9999,99 mm / ±399.9995 in
±999,999 mm / ±39.99995 in
Inductive system
1 x 3 V lithium battery, type CR2032, 220 mAh
8'000 hours
RS232 compatible
+5 to +40°C (-10 to +60°C)
as per EN 61326-1
Ø 8 h6 (3/8''), interchangable M2,5 (4-48-UNF) probe (as per DIN 878)
11
01930321 (0,001 mm)
12,5 mm
10 µm
4 µm
2 µm
119 g
0,65-0,9 N
1,7m/s
MIN/MAX mode : 20 mes/s
75 µA
IP51
