Model assembly
Float set installation
1.Install the two cross members and the front and rear float struts
between the left and right floats as shown. Secure the assembly
together with the eight included set screws.
2. Insert the front and rear struts into the float slots on the bottom
of the fuselage, and secure them in place with the eight included
screws and brackets.
3. Connect the float servo lead to the rudder extension in the
fuselage.
NOTE: make sure the servo plugs are firmly inserted

Battery installation

1.Pull back on the latch and remove the battery hatch.
2.Apply the hook tape to the cable end of the battery.
3.Slide the full charged battery into the battery compart-
ment wtith the power supply cable toward the rear end of
the plane.
Note: The center of gravity can be adjusted by moving
the battery forward or aft. Having the correct center of
gravity is critical to achieving proper flight characteristics.
HKM3.0*16
7
E
N
机米 3*4
