User Manual of Brushless Speed Controller

IMPORTANT WARNINGS
ESC is not responsible for your use of this product, or any damage
or injuries you may cause or sustain as a result of its usage.
Always place safety as priority when you use the product.
An electric motor that is connected in combination with a battery
and/or ESC may start unexpectedly and cause serious damage
and so should always be used with care and respect.
We recommend you always remove the propeller when working
on a model with the power source connected.
Follow and observe all local laws and by-laws relating to model
flying when flying RC planes.
Never fly over others or near crowds.
SPECIFICATION
Type PN#Model
Beatles 20A SBEC G2
Beatles 30A SBEC G2
Beatles 40A SBEC G2
Beatles 50A SBEC G2
Beatles 60A SBEC G2
Beatles 80A SBEC G2
Beatles 100A SBEC G2
Wires Connection:
The speed controller can be connected to the motor by soldering
directly or with high quality connectors. Always use
newconnectors, which should be soldered carefully to the cables
and insulated with heat shrink tube. The maximum length of the
battery pack wires shall be within 6 inches.
Solder controller to the motor wires.
Solder appropriate connectors to the battery wires.
Insulate all solder connectors with heat shrink tubes.
P u l t g e h " R J c " n o e n t c r o t n i t o e h e r
Controller Red and Black wires connects to battery pack Red and
Black wires respectively.
THROTTLE CALIBRATION
(Important: Please make the throttle calibration for the first time
using ESC!!!)
Turn on the transmitter,
move the throttle
stick to the top position.
The motor will beep several
sounds, sounds time presents the
amount of battery cells.
When the motor emits " Beep----Beep" , means the ESC is ready
to work.
Cont./Burst
Current(A)
3020211 20A/30A
3030211 30A/40A
3040211
40A/55A
3050211 50A/65A
3060211 60A/80A
3080211 80A/100A
3100211 100A/120A
e c v i r e h t t o r e l t c a h n n . l e
Connect the battery pack to
the ESC and wait for about
2 seconds.
The motor will beep for
twice, then move the
throttle stick to the
bottom position in 3 seconds.
KEY FEATURES
1. Utilizes powerful next generation MOSFET with a low thermal
signature, high peak current threshold and reliability.
2. Features high performance 32bit microprocessor as standard.
Stronger computing ability and faster processing rates.
3. Super smooth start up and throttle throughout the power range.
4. Higher driving efficiency and more energy-saving.
5. Adjustable SBEC output voltage, 5V/6V. (40A/50A/60A/80A/100A
have SBEC adjustable)
6. Multiple protection protocols: start-up, over-heat, low-voltage
cutoff, signal loss, phase loss etc.
7. Supports wide range of high RPM type motors commonly found
in today's market.
8. Fully programmable via optional ZTW mobile app or ZTW LCD
programming card.
Battery cell Weight
NiXX\Lipo (g)
5-12NC\2-4Lipo 25
5-12NC\2-4Lipo 25
5-12NC\2-4Lipo 37
5-12NC\2-4Lipo 37
5-18NC\2-6Lipo 50
5-18NC\2-6Lipo 75
5-18NC\2-6Lipo 80
Throttle Signal Wire
Reverse
Signal
Receiver
Wire
NORMAL STARTUP PROCEDURE
Turn on the transmitter,
move the throttle stick to
the bottom position.
When the motor emits
" Beep----Beep" , means
self-test is finished, the ESC
is ready to work.
12
BEC Size(mm)
Output L*W*H Program
5.5V/4A 60*25*10
5.5V/4A 60*25*10
5V/6V 4A 68*25*10
5V/6V 4A 68*25*10
5V/6V 8A 70*34*10
5V/6V 8A 90*37*10
5V/6V 8A 90*37*10
ESC
Connect the battery pack to
the ESC and wait for about
2 seconds.
The motor will beep several
sounds, sounds time presents
the amount of battery cells.
User
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Motor
Battery
