Advancing the Line Using
the Bump Feed
1. Run the tool at full throttle.
2. Tap the bump head on the ground to advance
the line. The line advances each time the bump
head is tapped.
Note:
Do not hold the bump head on the ground
while running the trimmer.
Note:
The line trimming cut-off blade on the
grass deflector cuts the line to the correct length.
Figure 12
1. Bump head
Note:
If the line is worn too short, you may not be
able to advance the line by tapping it on the ground. If
so, release both triggers and refer to
Line Manually (page 13).
Advancing the Line
Manually
Remove the battery pack from the trimmer, then push
the bump head while pulling on the trimmer line to
manually advance the line
If pushing the bump head does not advance the line
it may be jammed. Remove the bump head cover
by pushing in on the tabs on either side of the bump
head, remove any debris or tangled line, then snap
the bump head cover back into place
Advancing the
(Figure 12).
(Figure 13).
Some parts not shown for clarity
1. Push in on the tabs to access the line directly.
Operating Tips
•
Keep the trimmer tilted toward the area being cut;
this is the best cutting area.
•
The string trimmer cuts when you move it from
left to right; this helps prevent the trimmer from
throwing debris at you.
•
Use the tip of the line to do the cutting; do not force
g399657
the trimmer head into uncut grass.
•
Wire and picket fences, stone and brick walls,
curbs, and wood can cause the line to wear rapidly
and break.
•
Avoid trees and shrubs; the line can easily damage
tree bark, wood moldings, siding, fence posts, and
other soft materials.
1. Direction of rotation
13
Figure 13
Figure 14
2. Line path
g386222
g399658
