Via the operating voltage of the
outdoor unit
For this purpose, terminal 1 of the door
opener is connected to Terminal 10, terminal
2 of the door opener to earth/GND (e.g. Ter-
minal A2). In addition, a bridge of +15V (e.g.
A1) to terminal 11 is required.
With an external voltage source (e.g.
bell transformer, max. 12V/1A).
This requires separate lines from the external
voltage source to the door opener and to the
outdoor unit.
Connection 1 of the door opener is connected
directly to connection 1 of the external
voltage source. Connection 2 of the door
opener is connected to terminal 11, connec-
tion 2 of the external voltage source is con-
nected to terminal 11.

INITIAL OPERATION

After all components have been mounted
and connected correctly, connect the power
supply. Then you must ring once at the out-
door unit (if there are several outdoor units,
you must ring once at each one) to initialise
the system. This initialisation must be carried
out each time the power supply is interrup-
ted.
