m-e ADV-1010 Bedienungsanleitung Seite 23

2
Fig.
11
12
10
2
1 = Name plate
2 = Housing screws
3 = Front housing
4 = Adjustment cover screws
5 = Adjustment cover
6 = Technical unit screws
7 = Technical unit
8 = Mounting screws
9 = Microphone
10 = Connection terminal
13
8
9
11 = Protective roof
12 = Protective roof screws
13 = Loudspeaker opening
6
4
14
6
23
ENGLISH ADV-1010
ADV-1020
1
3
GB
