Tab. 66:
Byte Content
7 Auto-negotiation
I/O Data
Die Bit-Zuordnung für die I/O-Daten entnehmen Sie der folgenden Tabelle.
Tab. 67:
Direction
Input
Input
Input
Output
UM Config GRS106 HiOS-2S
Release 9.4 07/2023
Port-Status/Port-Parameter
Geräte-I/O-Daten
Byte
Bit values:
0
1
2
Access Value Meaning
ro 0 Unavailable
1 Disabled
2 Enabled
Bit Meaning
0 OK or unavailable
1 Reason for report exists
General
0 Device status
1 Signal contact 1
2 Signal contact 2
3 Temperature
4 Fan
5 Module removal
6 ACA removed
7 Not used
Power supply status
0 Power supply unit 1
1 Power supply unit 2
2 Power supply unit 3
3 Power supply unit 4
4 Power supply unit 5
5 Power supply unit 6
6 Power supply unit 7
7 Power supply unit 8
Supply voltage status
0 Not used
1 Not used
2 Connection error
3 Not used
4 Not used
5 Not used
6 Not used
7 Not used
Not defined
Industrieprotokolle
15.3 Funktion PROFINET
