Industrieprotokolle
15.2 Funktion EtherNet/IP
Tab. 54:
Instance
151
152
153
154
Tab. 55:
Id Attribute
1 Revision
2 Largest Instance
Number
3 Number of
Instances
Currently Existing
4 Optional Attribute
List
5 Optional Service
List
6 Maximum ID
Number Class
Attributes
7 Maximum ID
Number Instance
Attributes
Tab. 56:
Id Attribute
3 Data
4 Size

Connection-Manager

Die Connection-Manager-Klasse (Class Code 0x06) ordnet und verwaltet die internen Ressourcen,
die den I/O- und Explicit Messaging-Verbindungen zugeordnet sind.
Tab. 57:
Id Attribute
1 Revision
2 Largest Instance
Number
3 Number of
Instances
Currently Existing
280
Unterstützte Instanzen (Forts.)
Description
CONFIG_ASSEMBLY_NUM
HEARBEAT_INPUT_ONLY_ASSEMBLY
HEARBEAT_LISTEN_ONLY_ASSEMBLY
EXPLICT_ASSEMBLY
Class-Attribute
Access
rule
Get
Get
Get
Get
Get
Instanz-Attribute
Access
Rule
Get
Get
Class-Attribute
Access
rule
Get
Get
Get
Data type Description
UINT Revision: 2
UINT Largest instance number: 154
UINT Number of instances currently existing: 7
Unsupported
Unsupported
UINT Maximum ID Number Class Attributes: 7
UINT Maximum ID Number Instance Attributes: 4
Data type Description
ARRAY of:
BYTES
UINT Number of bytes in Attribute 3
Data type Description
UINT Revision: 1
UINT largest instance number: 1
UINT Number of instances currently existing: 1
Service
Get_single/Set_single
Get_single/Set_single
Get_single/Set_single
Get_single/Set_single
