- 4 -
Alle Ausführungen sind für den Betrieb ohne Drehzahlrück-
führung mit einer Kompensationsschaltung für Fluss und
Schlupf in Abhängigkeit des Moments ausgestattet.
Der Fluss im Motor bleibt annähernd konstant. Diese Kom-
pensation beeinflusst das Überlastverhalten des Frequenz-
umrichters sehr positiv. Die Gefahr des Kippens wird deutlich
reduziert.
Bei richtiger Einstellung kann eine Drehzahlkonstanz von
ca. 1 % der Nenndrehzahl erreicht werden.
U2 Frequenzumrichter sind entsprechend
den verschiedenen Anwendungen standardmäßig für zwei
Überlastarten ausgelegt:
♦ Normaler Betrieb mit 50 % Überlastfähigkeit.
Typische Anwendungen sind Verpackungsmaschinen,
Fördertechnik usw.
♦ Betrieb bei erhöhter Leistung mit 15 % Überlastfähigkeit.
Typische Anwendungen sind Lastarten mit quadratischer
Momenten-/Drehzahlcharakteristik wie Lüfter, Pumpen
Bild 3-4:
Momentenverlauf mit der Drehzahl
Fig. 3-4: Torque-speed characteristic
Bei Betrieb oberhalb der Grundfrequenz fällt das verfügbare
Moment mit zunehmender Drehzahl stark ab (Gefahr des
Motorkippens bei tacholosem Betrieb).
Die U/f-Kennlinie ist für Grundfrequenz 230 V / 50 Hz bzw.
400 V / 50 Hz voreingestellt. Für Sonderanwendungen kön-
nen abweichende Grundfrequenzen eingestellt werden,
siehe Seite 10.
Ausführungen
Bemessungswert
der Netzspannung/
Rated value of
supply voltage
DC
500...680 V
3AC
400...480 V
Einsatzbereich
(Motor 3AC 400 V)
Range of
DC
250...680 V
application
3AC
200...480 V
(Motor 3AC 230 V)
KM
= Normaler Betrieb mit 50 % Überlastfähigkeit
QM
= Betrieb mit erhöhter Leistung mit 15 % Überlastfähigkeit
Andere Spannungen auf Anfrage
Optionen und Zubehör
Siehe Seite 24
usw.
2
Überlast/
Overload
Normaler Betrieb
1,5
mit 50 % Überlastfähigkeit (KM) /
M
Normal operation
M n
with 50 % overlad capability (CT)
1
U0
0
1
n
n
N
Lastart/
Max. Nennleistung des Motors / Max rated motor power [kW]
Torque
2,2
3
4
5,5
7,5
type
4
7
KM /CT
U2
U2
4
QM /QT
U2
4
7
15
KM /CT
U2
U2
U2
4
7
QM /QT
U2
U2
All versions are fitted for operation without speed feedback
loop with a special circuit for compensation of flux and slip
depending on load.
The flux in the motor remains approximately constant.
This flux compensation provides a very good overload
characteristic of the inverter. The risk of failing out of
synchronism is reduced considerably.
When correctly adjusted, operation with speed holding at
approx. 1 % of rated speed is possible.
To cater for a wide range of applications
U2 Frequency Inverters are designed for two different
types of overload:
♦ Normal operation with 50 % overload capability.
Typical applications are packaging machines, transport
applications etc.
♦ Operation at higher powers with 15 % overload capability.
Typical applications are loads with a quadratic torque/
speed characteristic such as with fans, pumps etc.
2
M
M n
1,15
1
2
0
The available torque above base frequency falls off rapidly
with increasing frequency (danger of motor stalling without
speed detection).
The V/f characteristic is preset for a base frequency of
230 V / 50 Hz or 400 V / 50 Hz. Other base frequencies can
be selected for special applications, see page 10.
Available types
11
15
18,5
22
30
37
15
22
30
U2
U2
U2
7
15
22
30
U2
U2
U2
U2
22
30
45
75
U2
U2
U2
U2
15
22
30
45
U2
U2
U2
U2
CT
= Normal operation with 50 % overload capability
QT
= Operation at higher power with 15 % overload capability
For other voltages please inquire
Options and Accessories
Refer to page 24
PB-TU2-18-10-10 - 1101-103/06
Überlast/
Betrieb bei erhöhter Leistung
Overload
mit 15% Überlastfähigkeit (QM) /
Operation at higher power
with 15% overlad capability (QT)
U0
1
2
n
n
N
45
55
75
90
110 132 160 200
45
75
110
160
U2
U2
U2
U2
45
75
110
U2
U2
U2
110
160
U2
U2
75
110
160
U2
U2
U2
160
U2
