ALPA MEGArod Bedienungsanleitung Seite 6

ALPA_DIGITAL_INDICATOR_MEGArod IP67/IP54
OPERATING FEATURES OF THE INSTRUMENT
MODE
The instrument has two operating modes: basic functions (direct access) and advanced
functions. In addition to the configuration functions, 2 working reference functions can
be accessed, in MIN, MAX and DELTA (TIR) mode, plus Tolerance display or input of a
multiplication factor other than 1:1
The «favourite» key gives direct access to the function used most often
SET
Sets a Preset value, verifies a selection, and controls switching off the instrument.
By default, SIS mode enables automatic switch-off with no loss of origin
Personalising the functions - It is possible to activate or de-activate certain functions of the instrument via RS232
RS232 commands - Direct RS232 to 4800 Baud connection, 7 bits, even parity, 2 stop bits
START
Press a button. When used for the first time, the instrument requests selection of the measurement unit
required (MM or Inch). Choose..... then measure.
