OPERATION

After connecting the device to the mains it is ready for operation. The display indicates the last operating
mode. The operating modes can be selected by means of the display and the control buttons. All settings
remain stored even if the device is disconnected from the mains. The device can be operated in stand-alone
mode via the control board or in DMX-controlled mode via any commercial DMX controller as well as
wireless via QuickDMX
Transmitter/Receiver.
After you connected the effect to the mains, the EUROLITE LED TSL-350 Scan COB starts running. During
the Reset, the motors are trimmed and the device is ready for use afterwards.

Control Board

The Control Board offers several features: you can e. g. easily set the starting address.
The main menu is accessed by pressing the Mode button. Browse through the menu by pressing the Mode
button. Press the Enter button in order to select the desired menu. You can change the selection by
pressing Up or Down. Confirm every selection by pressing the Enter button. You can leave every mode by
pressing the Mode button. The functions provided are described in the following sections.
Main menu
DMX Set
Address
Mode Set
Show Mode
Sound Mode
Sound Sense
No DMX Set Blac/Auto/Sound/Hold
Back LCD Light
Pan Inverse
Tilt Inverse
Fixture Reset
Completely remove the transport safeties (cable ties) at the mirror.
(Only necessary at initial start-up!)
with the optionally
Sub menu
A001-A512 DMX address setting
Master/Slave setting
With this function, you can define the device as Master or as
Mast/ Slave.
Slve1/Slve2 Mast: Master-Mode setting
Slve1: Slave-Mode 1
Slve2: Slave-Mode 2
Show 1/2/3/0 Internal programs 0 – 3 (Auto)
ON/OFF Sound controlled mode
0-100 Microphone sensitivity (increasing)
Status if no DMX-signal
Blackout/Auto/Sound/Hold
Display turn off
OFF/ON ON - Display always on
OFF - Shuts off the display after a few seconds
OFF/ON
Reverse PAN/TILT movement
OFF/ON
Yes/No Reset
available EUROLITE
Function
23/28
