DMX operation

Setting the number of DMX channels and the DMX starting address
For operation with a controller with DMX512 protocol, the device is equipped with 4 control channels.
However, it can also be switched to a mode with 1 or 2 channels if different functions are required. To be
able to operate the device with a DMX controller, the DMX starting address must be set. The starting
address depends upon which DMX controller is being used. Please refer to the controller's documentation.
1 Press the MENU button so many times until DMX is indicated in the display. Confirm with the ENTER
button.
2 The display indicates 1 CH (1 DMX channels), 2 CH (2 DMX channels) or 4 CH (4 DMX channels). Use
the buttons UP and DOWN to select the desired DMX channel mode. Confirm with the ENTER button.
3 Now the display indicates the menu item for the DMX start address ADDR***. Use the buttons UP and
DOWN to set the address. Confirm with the ENTER button.
Note: Please make sure that you do not have any overlapping channels in order to control each device
correctly and independently from any other fixture on the DMX chain If several devices are addressed to the
same address, they will work synchronously.
Functions in DMX mode
1-channel mode
Channel
1
2-channel mode
Channel
1
Master dimmer
2
Strobe effect
4-channel mode
Channel
1
Master dimmer
2
Strobe effect
3
4
Auto programs
Value Function
000 – 255 Warm white 0-100%
Value Function
000 – 255 Total brightness 0-100 %
000 – 009 No function
010 – 255 Strobe effect, slow > fast
Value Function
000 – 255 Total brightness 0-100 %
000 – 009 No function
010 – 255 Strobe effect, slow > fast
000 – 255 Warm white 0-100%
000 – 009 No function
010 – 069 Auto program 1
070 – 129 Auto program 2, slow > fast
130 – 189 Auto program 3, slow > fast
190 – 255 Auto program 4, slow > fast
