DESCRIPTION OF THE DEVICE

2
1
(1) Stand/mounting bracket
(2) 200 W WW COB LED
(3) Infrared sensor for the remote control
(4) Fixation screw
(5) DMX input
(6) Antenna for QuickDMX
(7) LC display with operating buttons
Note: When connected correctly, the power and DMX sockets are protected from spraying water according
to IP65. When not in use, make absolutely sure to close the sockets with the rubber sealing caps.
3
4
6
5
10
(8) ON/OFF switch
(9) DMX output
(10) Pressure compensation plug
(11) Power in
(12) Safety eyelet
(13) Power out
23/36
7
8
9
11 12
13
