Wireless via QuickDMX

Connect the QuickDMX transmitter to the DMX controller. Put the transmitter and the AKKU IP Tourlight into
operation and set them to the same transmission channel. Use menu option SET 2.4G on the spotlight to do
this. Thus, the wireless DMX network is set up and the spotlight is paired to the QuickDMX transmitter. The
assignment of the spotlight to the transmitter is kept memorized even after disconnecting the power supply.

Transmission modes

QuickDMX allows creating reliable point-to-point, point-to-multipoint and even multipoint-to-multipoint
installations over large distances and in any environment (please refer to the controller's documentation). A
single QuickDMX transmitter transmits all 512 DMX channels to a maximum of 512 spotlights. It is possible
to operate 6 transmitters at the same time in order to control a total of 3072 DMX channels. The maximum
range is 400 m.
Point-to-point connection:
Point-to-multipoint connection:
