12. Technical Data

Image Sensor
Sensor
Lens
Angle of View
Video Properties
Video Encoding
Video Framerate
Supported Resolutions
Flip / Mirror Image
Video Settings
Communication
Network Interface
Wireless (not for PoE version)
WiFi Frequency Range
WiFi Transmission Power
WPA / WPA2 Encryption
PoE (only for PoE version)
Hardware
PIR Detector
Infrared LEDs
White lights
MicroSD Card Reader
Power Supply
Power Consumption
Operating Temperature
Requirements
Web Browser
CPU / Graphic Card
Bandwidth
Go to http://install.instar.com
1/3" WQHD Sony STARVIS IMX335 CMOS Sensor
f = 2,8mm - 12mm; F/1.6 (Wide) - F/2.95 (Tele)
30° - 120° diagonal field of view
h.265 / h.264 high, main and baseline / MJPEG
Up to 30fps
2560x1440, 1920x1080 und 1280x720 Pixel
Horizontal / vertical
Brightness / contrast / saturation / exposure...
10Base-T/100Base-TX ethernet port
5GHz / 2.4GHz, Wi-Fi 5 (802.11ac)
2.4 - 2.4845Ghz, 5,150 - 5,350 / 5,470 - 5,725Ghz
<16dBm @ 11b/g, <15dBm @ 11n <18dBm@ 11ac
TKIP / AES (CCMP)
IEEE 802.3af (+ Pin 4 and 5 / - Pin 7 and 8)
Passive Infrared Motion Detector
6 High-Power IR LEDs / 20-25m effective range
6 high power Illumination Light Source-LEDs
For MicroSD / SDXC cards up to 256 GB
Output: 12V DC 2A / Input: 110-240V
Max. 16 Watt (in normal operation 5 Watt)
- 20°C to 55°C
Web browser supporting HTML5
Dual core (min. 2Ghz) / 256MB+ graphic card
Min. 512kbs per camera
