1 - Wall Bracket
2 - Ceiling Bracket
3 - Antenna Connector
4 - Dual LEDs
5 - Autofocus Lens
6 - Photo Sensor
7 - PIR Sensor
8 - Microphone
9 - Status LEDs
10 - MicroSD card slot
11 - Loudspeaker
12 - Alarm input
13 - Alarm output
14 - Reset
15 - Network LED
16 - Network Port
17 - Power Connector
18 - Connection Cable
Go to http://install.instar.com
Wall mounting
Overhead installation
RP-SMA WiFi antenna connector (not for PoE version)
6 high-power IR LEDs (@ 850nm)
6 high-power floodlight LEDs
4x optical zoom lens with autofocus (2.8mm - 12mm)
Twilight switch for IR LEDs
Integrated Panasonic passive infrared (PIR) motion detector
For noise detection and audio recording
Red: Camera on or blinking during firmware update
Blue: On during WiFi, blinking during WPS or reset
Slot for MicroSD/SDXC cards (max. 256GB)
- 32GB included inside the camera -
Integrated loudspeaker
Input for potential free external alarm sensors
Output (relay) can support max. 24V/1A
Press 20 seconds for reset
Indicator for network status
On: connected to network by network cable
Off: No power, Wifi connection or no network cable connected
RJ45 LAN port / connector for Cat5e LAN cable or higher
For included 12V / 2A power supply
With LAN- and power connector as well as alarm input,
as alarm output, reset
6-EN
