Information about the device

Description of the device
This device uses the principle of condensation to automatically
dehumidify rooms. To do so, the device can be used in continuous
operation.
The fan sucks damp room air through the air inlet (2), the air
filter (3), the evaporator and to the condenser located behind it.
The air is cooled at the cold evaporator until it is below the dew
point. Water vapour contained in the room air precipitates on the
evaporator fins as either condensation or frost. The dehumidified,
cooled air is warmed again and blown out from the air outlet (6).
The drier air which is prepared in this way mixes with the air in the
room. The humidity in the room where the device is positioned is
reduced as air constantly circulates through the device. Depend-
ing on the air temperature and the relative humidity, the con-
densed water either drops continuously or only during the defrost
phase into the condensation tray. The condensation is fed through
a pressure-resistant pipe connection and out of the device at a
preinstalled condensation drain hose (5).
The condensed water can be diverted by retrofitting a condensa-
tion pump.
For easy transport, the device is fitted with a bar handle (1) and
wheels (4). In working position, the device sits tilted on the stand
bar (7).
The device can reduce the relative humidity of a room by up to
approx. 35 %. Because of the heat radiation which is tied up in
operation, the room temperature can rise by approx. 1 – 3 °C.
EN
Device depiction and operating elements
5
4
7
No. Operating element
1 bar handle
2 air inlet
3 air filter
4 wheels
5 condensation drain hose
6 air outlet
7 stand bar
Scope of supply (standard)
• construction dryer TTK 800
• air filter
• condensation drain hose
• operating manual

Optional accessories

• air filter
• humidistat
• condensation pump
• energy cost gauge
Operating Manual – Construction dryer TTK 800
1
2
3
6
