Switching The Device On/Off; Menu And Programme Modes; Programme Mode "Deodor - Trotec INT Bedienungsanleitung

Switching the device on/off

Warning!
Risk of injury due to Ozone!
Leave the room immediately
after switching on and/or ac-
tivating the device in order
to avoid any contact with the
ozone.
Switch the odour neutraliser on by setting the power
switch (1) to the position "I".
About 75 seconds after switching on the device,
ozone generation is started.
Switch the device off by setting the power switch (1)
to the position "0".

Menu and programme modes

F0 F1
Esc
0 1
5 6
Fig.: Control panel
The device offers different programme modes that
can be used according to individual application re-
quirements:
• "Deodor"
• "Service"
• "Manual"

Programme mode "Deodor"

This is the standard programme mode for room treat-
ment. Different preset values for room size and the
duration of treatment can be selected. This way, room
treatment can be adapted and carried out according
to individual requirements. When selecting or entering
the parameters, please proceed as follows:
1. Press "0" to select the programme mode
"Deodor".
B-6
F2 Up
3 4
2
Left Right
8 9
Enter
7
Down
Operating manual – Airozon Supercracker
2. Press "4" to proceed to the next menu item.
Here, you can set the size of the room. You have
the following options:
• "Small" (press 0) for room sizes up to 30 m²
• "Medium" (press 1) for room sizes between
30 and 60 m²
• "Large" (press 2) for room sizes between 60
and 100 m²
• "X-Large" (press 3) for room sizes exceeding
100 m³
3. Press "4" to select the menu item "duration of
treatment". You have the following options:
• "Short" (press 0)
• "Intermediate" (press 1)
• "Long" (press 2)
The combination of the preset options for room size
and duration of treatment corresponds to the follow-
ing time values:
Duration of treatment/min
Room size Short
Small 15
up to 30 m³
Medium 30
30-60 m³
Large 60
60-100 m³
X-Large 300
>100 m³
Additionally, an individual time can be set. Proceed as
follows:
• Select the function "Set Time" (press 3)
• Use the number keys 0-9 and the keys "Left"
and "Right" to enter the desired time. The
adjustable range lies between 25 and 1,440
minutes.
• Now, press 4 to proceed to the next menu
item and to start the device.
Intermediate Long
40 180
60 180
180 1.440
720 2.880
EN
