- If the pad is dirty, wash it at a maximum
temperature of 60 °.
- If the brush is dirty, wash it under running
water.
- Unplug the power cable from the socket
and wrap it around the cable reel sup-
ports.
For machines equipped with moveable hooks:
- Roll up the cable on the supports (66)
(Fig. 25).
- To remove the cable from the supports,
turn the hooks (67) inward and remove
the cable without necessarily unwinding
it (Fig. 26).
For machines not equipped with moveable
hooks:
- Place the fixed support at the bottom of
the handle rod and wrap the cable, pass-
ing it between the support and the guide
handle (Fig. 27).

6.1.f - Transport

Making sure that the mains plug is discon-
nected and the handle is in an upright posi-
tion, lift the machine body by turning the han-
dle downwards.
The machine can then be transported on the
wheels.
7.1 MAINTENANCE AND
CLEANING
WARNING:
For information and warnings relating
to maintenance or cleaning, follow what
is described in the "Safety warnings for
single disc" manual, accompanying this
document.
OPERATIONS TO BE
CARRIED OUT EVERY DAY

7.1.a - Cleaning the machine

Clean the machine with a damp cloth and
then wipe it with a clean, dry cloth to prevent
the formation of scale due to the effect of
chemicals.
WARNING:
Do not use solvents, acids or corrosive
substances for cleaning the machine.
7.1.b - Emptying and cleaning the
water tank (optional)
WARNING:
Once you have finished washing, you
must drain and clean the water tank to
prevent deposits or scale.
To empty the water tank, release it from its
supports.
WARNING:
Store the appliance in a dry, sheltered
place.
ENGLISH - 8
