Calibration
3
1. Place the measuring face (17) on an even surface
with position mark. Switch on device (3). To access
calibration mode simultaneously press buttons 3
and 8. -1- appears on the display.
2. Press the ON/OFF button (3) again. -1- flashes.
The display then changes to -2-.
3. Turn the spirit level by 180° and place it exactly
on the marked surface. Now press the ON/OFF
button (3). -2- flashes. Calibration is concluded
when the measured value appears on the display.
Reference function to transfer angles
4
1. ABS mode
MasterLevel Box
ZERO
HOLD
4. Relative measuring
mode
HOLD
5
Press the HOLD button (9) to hold the current measured value on
the display.

Auto Off function

In order to preserve the battery, the measuring device switches off
automatically if it is left idle for 5 minutes.

Error code

– – – – Alignment of the vertical axis is outside the tolerance range
08
EN
2. ABS mode
5. ABS mode
MasterLevel Box
HOLD
MasterLevel Box
A quality product from
GmbH & Co. KG
Donnerfeld 2, 59757 Arnsberg,
Germany, Tel.: +49 2932 638-300,
Fax -333, www.laserliner.com
3. Relative measuring
mode
ZERO
