14. Maintenance

Air filter
WARNING! Never operate the machine without the air filter; dirt could be
sucked in and interfere with the function of the machine. Disconnect plug
before changing parts.
•
Press both locks (Fig. 12.1) and remove the filter cover.
•
Remove the air filter (2) and replace depending on contamination.
•
Click the filter cover in place again.
Ventilating hose/Valve
•
Pull the ventilating hose (Fig. 10, 13) at the top from the gun body. Screw off the valve
cover (14). Remove the diaphragm (15). Carefully clean all parts or replace in the event
of damage.
•
Place the diaphragm (Fig. 10, 15) with the pin facing upwards on the bottom section
of the valve. Also see the marking on the gun body.
•
Place on the valve cover (Fig. 10, 14) and screw it closed.
•
Place the ventilating hose (Fig. 10, 13) on the valve cover and on the nipple at the gun
body.

15. Spare Parts List

Pos. Designation
1 Standard small spray attachment complete incl. 600 ml
container
2 Union nut
3 Air cap
4 Nozzle
5 Nozzle seal
6 O-ring
7 Material volume regulation with spring, complete
8 Ventilating hose, valve cover, diaphragm
9 Container seal
10 Suction tube
11 Container with cover
12 Air filter
13 Air filter cover
14 Stir stick
15 Lubricating grease (no fig.)
24
Spare Parts List (Fig. 13)
W 150
Order No.
2370525
2362873
2362877
2362878
0417706
2362875
0417910
2304027
2370527
2371151
2370528
2370530
2370532
2304419
2315539
