Installation Of The Rotor Guards; Getting Started - XciteRC Rocket260 Bedienungsanleitung

Installation of the rotor guards · Getting started
• WARNING: The Quadrocopter battery is polarized. Check the side channels. Do not use force - fi re
or explosion hazard!
• The red LED goes out to indicate charging. Charging time is about 120 minutes. If the battery is fully
charged, the red LED lights up again.
• Unplug the battery and the USB cable.
The fl ight time of the Quadrocopter is about 6-8 minutes.

Installation of the rotor guards

Mount the rotor guard with the delivered screws as follows:

Getting started

Before you begin please check:
• WARNING: Only start with a suffi ciently full transmitter batteries (rechargeable batteries) and fully
charged drive battery – crash hazard!
• Check all parts for damage and dirt. Replace any damaged parts and clean the model, because dirt
increases the weight and therefore can degrade the fl ying qualities.
1
• Connect the battery (1) and place into the battery compartment on the bottom (2). Close the cover (3).
Then switch on the transmitter. The POWER LED fl ashes.
• WARNING: The battery connector is polarized. Check the side channels. Do not use force - fi re or
explosion hazard!
Power switch on the back of
the quadrocopter.
• Place the Quadrocopter on a fl at surface in the starting position and switch it on (1). Then switch the
transmitter on (2). Move the left throttle lever all the way up and then back in the lowest position (3). This
safety circuit prevents the rotor may start after turning ON the Quadrocopter
• The model is ready to fl y as soon as a short beep is heard. The POWER LED of the transmitter and the
Quadrocopters LED lights up solid.
XciteRC Rocket 260 3D
1
2
1
- LED flashing fast: automatic
detection
- LED flashing slowly: ready to
bind
- LED on: Binding completed
4
2
3
1. First move up
2
2. Move down immediately
5
Direction
Flying (L/R)
sideways
EN
3
3
6
Rudder
Turning
(L/R)
19
