EN
Step 1.
Remove the paper cover and fix the front base (33) to the main frame (1)
with bolts (30), curved washers (31), and nuts (32).
Step 2.
Remove stoppers (24), screws (45), and the back plate (44).
Lock the saddle with the slider (18) on the slider track (22) and retighten
the locks (24) and the back plate with screws (45).
Step 3.
Fix the rear base (29) to the slider track (22) with the hexagonal bolt (25)
with the flat washer (8) and the nylon nut (9).
Then put the cover (28) onto the rear base (29) and screw it with screws
(27). Screw the knob (2) on.
Step 4.
Connect the connecting cable (46) to the computer cable (36).
Next, fix the slider track (22) to the main frame (1) using the hexagonal bolt
(14) with flat washers (8) and the nylon nut (9). Install hole plugs (70).
Screw on the know (2) with the flat washer (35) and knob (15).
Attach pedals (11L/R) to the main frame (1) with bolts (12) and flat washers
(10).
NOTE! The right pedal is marked 'R', and the left pedal is marked 'L'.
