Bedienung und Installation Operation and installation Gebruik en Installatie Obsluha a instalace SNU 5 Plus / SNU 5 Plus AU / SNU 5 Plus GB / SNU 5 Plus 1 kW Kleinspeicher (drucklos) Small water heater (non-pressuri- sed) Kleine boiler (drukloos) Malé zásobníky (beztlakové)
Art der Gefahr Verletzung Lesen Sie diese Anleitung vor dem Gebrauch sorg- fältig durch und bewahren Sie sie auf. Geben Sie die Anleitung ggf. mit dem Gerät weiter. www.stiebel-eltron.com SNU 5 Plus | AU | GB | 1 kW |...
Schützen Sie das Gerät und die Armatur vor Frost. – Warnung - Um die Sicherheit dieses Geräts zu gewährleis- ten, muss es gemäß den Anweisungen des Herstellers in- stalliert, betrieben und gewartet werden. | SNU 5 Plus | AU | GB | 1 kW www.stiebel-eltron.com...
HINWEIS: Achten Sie darauf, dass die Wasseranschlüsse bei der Montage nicht geknickt werden. Vermeiden Sie Zugspannung beim Einbau. Inbetriebnahme (Fachkraft) HINWEIS: Stellen Sie die Spannungsversorgung erst dann her, wenn das Gerät vollständig mit Wasser befüllt ist! www.stiebel-eltron.com SNU 5 Plus | AU | GB | 1 kW |...
Wasserleitung sind nicht geschützt empfohlene Energiesparstellung ECO (ca. 60 °C), geringe Wasser- steinbildung 85 maximal einstellbare Temperatur HINWEIS: Die Fachkraft kann eine dauerhafte Temperaturbe- grenzung am Gerät vornehmen. | SNU 5 Plus | AU | GB | 1 kW www.stiebel-eltron.com...
Befestigungsschraube des Begrenzungsrings und u Ziehen Sie den Begrenzungsring ab. an dem Schutzleiterkontakt des Anschlusskabels. Anschlusskabel tauschen HINWEIS: Das Anschlusskabel darf nur von einer Fachkraft mit einem originalen Ersatzteil ersetzt werden. www.stiebel-eltron.com SNU 5 Plus | AU | GB | 1 kW |...
Wenn Sie die Ursache nicht beheben können, rufen Sie eine Fachkraft. u Teilen Sie der Fachkraft zur besseren und schnelleren Hilfe die Nummer vom Typenschild mit. | SNU 5 Plus | AU | GB | 1 kW www.stiebel-eltron.com...
Diese Rechte werden durch unsere Garantie gesetzlichen Gewährleistungsansprüche des Endkunden. Die nicht eingeschränkt. Die Inanspruchnahme solcher gesetzlichen gesetzlichen Gewährleistungsansprüche gegenüber den sonsti- Rechte ist unentgeltlich. gen Vertragspartnern des Endkunden sind durch unsere Garan- | SNU 5 Plus | AU | GB | 1 kW www.stiebel-eltron.com...
Rücknahme- und Entsorgungskonzept für die um- weltschonende Aufarbeitung der Verpackungen. Überlassen Sie die Transportverpackung dem Fachhandwerker beziehungsweise dem Fachhandel. Entsorgen Sie Verkaufsverpackungen über eines der Dualen Systeme in Deutschland. www.stiebel-eltron.com SNU 5 Plus | AU | GB | 1 kW |...
Seite 12
13.1 Dimensions and connections ......18 13.2 Wiring diagram..........18 13.3 Heat-up diagram..........19 13.4 Energy consumption data......... 19 13.5 Data table ............19 14 Guarantee ..............19 15 Environment and recycling........20 | SNU 5 Plus | AU | GB | 1 kW www.stiebel-eltron.com...
Pass on these instructions along with the appliance 3.1.3 Key to symbols as necessary. Symbol Type of risk Injury www.stiebel-eltron.com SNU 5 Plus | AU | GB | 1 kW |...
– Never subject the appliance to water pressure. The tap out- let has a vent function. Scale build-up can block the outlet and subject the appliance to pressure. – Never block the tap outlet. | SNU 5 Plus | AU | GB | 1 kW www.stiebel-eltron.com...
Commissioning may only be carried out by a qualified contractor in accordance with safety regulations. D0000105765 Filling the appliance with water D0000049325 u Open the cold water inlet of the distribution board. www.stiebel-eltron.com SNU 5 Plus | AU | GB | 1 kW |...
Undo the two screws securing the limiting ring in the cas- ing. u Re-insert the limiting ring with the required temperature limit. u Secure the limiting ring in the casing with the screws. | SNU 5 Plus | AU | GB | 1 kW www.stiebel-eltron.com...
After descaling, flush the heating element with clear water. No voltage at the ap- Check the plug / fuses Reassemble the appliance. pliance. in the distribution board. www.stiebel-eltron.com SNU 5 Plus | AU | GB | 1 kW |...
Isolate the appliance from the power supply by removing the plug or by switching off the MCB in the distribution board. u Drain the appliance (see chapter Draining the appliance [} 17] ). D0000105875 | SNU 5 Plus | AU | GB | 1 kW www.stiebel-eltron.com...
Stiebel Eltron Warranty for Small Water Heaters Mixed water amount 40 °C Who gives the warranty (10 °C/65 °C) The warranty is given by Stiebel Eltron (Aust) Pty Ltd (A.B.N. 82 Electrical data 066 271 083) of 294 Salmon Street, Port Melbourne, Victoria, 3207 (“we”, “us” or “our”).
Rating Label. 19. The Stiebel Eltron warranty for the unit is in addition to any rights and remedies you may have under the Australian Consumer Law. 15 Environment and recycling We would ask you to help protect the environment.
Seite 21
Montageschablone | Installation Template...
Lees deze handleiding voor gebruik zorgvuldig door genegeerd. Maatregel(en) voor het afwenden van het ge- en bewaar deze. vaar. Handelingsstap waarop de waarschuwing betrekking Overhandig de handleiding eventueel met het toe- heeft stel. | SNU 5 Plus | AU | GB | 1 kW www.stiebel-eltron.com...
Stiebel Eltron biedt een groot assortiment aan Mogelijke materiële schade geschikte kranen aan. – Vorst kan het toestel en de aangesloten kraan vernielen. Bescherm het toestel en de kraan tegen vorst. www.stiebel-eltron.com SNU 5 Plus | AU | GB | 1 kW |...
Zorg ervoor dat er tijdens het inbouwen geen trekspanning ontstaat. Ingebruikname (installateur) LET OP: Breng de spanningsvoorziening pas tot stand, wanneer het toestel volledig met water is gevuld! | SNU 5 Plus | AU | GB | 1 kW www.stiebel-eltron.com...
ECO (ca. 60 °C), weinig vorming van ketelsteen 85 maximaal instelbare temperatuur LET OP: De installateur kan een permanente temperatuurbe- grenzing op het toestel instellen. www.stiebel-eltron.com SNU 5 Plus | AU | GB | 1 kW |...
Trek de begrenzingsring van het toestel. Aansluitkabel vervangen LET OP: Laat de aansluitkabel altijd door een erkende installa- teur vervangen door een origineel vervangingsonderdeel. | SNU 5 Plus | AU | GB | 1 kW www.stiebel-eltron.com...
Harde kookgeluiden in Er heeft zich kalk afge- Ontkalk het toestel. voer het toestel. zet in het toestel. Warmwateruit- Buitendraad G 3/8 A loop Wandbevestiging Hoogte Gatafstand horizontaal mm www.stiebel-eltron.com SNU 5 Plus | AU | GB | 1 kW |...
SNU 5 Plus SNU 5 Plus verlenen wij geen garantie. Een eventueel door de importeur 1 kW verzekerde garantie blijft onverminderd van kracht. 204972 204973 Hydraulische gegevens | SNU 5 Plus | AU | GB | 1 kW www.stiebel-eltron.com...
Milieu en recycling 15 Milieu en recycling Wij verzoeken u ons te helpen ons milieu te beschermen. Doe de materialen na het gebruik weg overeenkomstig de nationale voorschriften. www.stiebel-eltron.com SNU 5 Plus | AU | GB | 1 kW |...
Seite 34
13.3 Diagram ohřevu ..........36 13.4 Údaje ke spotřebě energie........ 36 13.5 Tabulka s technickými údaji ......37 14 Záruka ..............37 15 Životní prostředí a recyklace........37 | SNU 5 Plus | AU | GB | 1 kW www.stiebel-eltron.com...
Informace pro Austrálii a Nový Zéland Úraz Instalace tohoto přístroje musí být v souladu s před- pisy Plumbing Code of Australia (PCA) a New Ze- aland Building Code. Úraz elektrickým proudem Popálení, opaření www.stiebel-eltron.com SNU 5 Plus | AU | GB | 1 kW |...
řovat nahoru. nací hodiny, bude mít za následek neúmyslnou deaktivaci bezpečnostního omezovače teploty. Přístroj nesmí být při- pojen k elektrickému obvodu, který je určitým zařízením pravidelně spínán a odpojován. | SNU 5 Plus | AU | GB | 1 kW www.stiebel-eltron.com...
– Vpravo modrá = „Přívod studené vody“ Dávejte pozor na to, že přístroj musí být připojen k ochrannému vodiči. – Vlevo červená = „Výstup teplé vody“ u Pevně přišroubujte připojení k rozvodům vody armatury k přístroji. www.stiebel-eltron.com SNU 5 Plus | AU | GB | 1 kW |...
Odpojte přístroj od síťového napětí. u Povolte šroubení připojení k rozvodům vody. u Přístroj sejměte z nástěnného držáku. u Přístroj s připojeními k rozvodům vody orientovanými smě- rem dolů nechejte vypustit nad dřezem. | SNU 5 Plus | AU | GB | 1 kW www.stiebel-eltron.com...
(> 0,4 l/min). voda. u Pokud nemůžete příčinu odstranit, zavolejte odborníka. u K získání lepší a rychlejší pomoci sdělte odborníkovi číslo z typového štítku. D0000105873 u Odmontujte přípojku „přítok studené vody“. www.stiebel-eltron.com SNU 5 Plus | AU | GB | 1 kW |...
Materiál tepelné izolace EPS + VIP EPS + VIP Materiál krytu/skříně Plast Plast Barva Bílá Bílá Přípojky Přípojka vody G 3/8 A G 3/8 A Rozměry Hloubka Výška Šířka Hmotnosti Hmotnost www.stiebel-eltron.com SNU 5 Plus | AU | GB | 1 kW |...
