look X-TRACK Anleitung Seite 13

3
SENS D'EXTRACTION DE L'AXE
DIRECTION OF AXLE REMOVAL
Instructions Axle
Maintenance X-TRACK LOOK Cycle
The axle is now released and can be removed. For routine maintenance, make sure to
keep the seal. If replacing the axle, use the new seal provided in the kit.
SEAL
BEARINGS X2 NUT
WASHER Ø6
