4. Press the switch lock (1) and the ON/OFF switch (2) and push the motor
down. Guide the saw forward to cut.
Note: To prevent the saw from kicking back during plunge cuts follow these
steps:
• Always place the plunge saw with the rear edge of the base plate (4) against
a fixed limit stop.
• Hold the plunge saw in both hands and slowly lower the saw blade.
• The cutting width marks (15) show the most foremost and rearmost cutting
points of the saw blade (Ø 165 mm) at maximum cutting depth and when
using the guide rail.

CHANGE SAW BLADE

Before any maintenance work always switch off the plunge saw and
disconnect from mains power!
1. Loosen both rotary knobs (7) and swivel the plunge saw to 0° position
before changing the saw blade. Tighten the rotary knobs again.
2. Set the selector switch (17) to the change saw blade icon.
3. Press the switch lock (1) down and push the motor down.
4. Press and hold the shaft lock down.
5. Use a 5 mm Allen key to turn the screw at the saw blade slightly clockwise
or counter-clockwise until the spindle clicks into place.
Shaft lock
Selector switch
