Accuracy
Test voltange
Test Frequency
Input protection
Temperature
Ranges
Resolution
Accuracy
Overload protection
Frequency
Ranges
Resolution
Accuracy
Sensitivity
Minimum pulse width
Duty cycle limits
Overload protection
Duty Cycle
Ranges
Resolution
Pulse widh
Frequency range
Accuracy
Overload protection
±(5.0 % rdg + 10 dgts) on 4μF range
±(5.0 % rdg + 5 dgts) on 40μF to 400μF
ranges
±(5.0 % rdg + 15 dgts) on 4000μF range
< 3.0 V
25Hz
0.315A/1000V fast blow ceramic fuse
6.3×32mm on μA/mA input
-20 °C to 1000 °C, -4 °F to 1832 °F
1 °C, 1 °F
±(2.0 % rdg + 4 °C) -20 °C to 10 °C
±(1.0 % rdg + 3 °C) 10 °C to 200 °C
±(3.0 % rdg + 2 °C) 200 °C to 1000 °C
±(2.0 % rdg + 8 °F) -4 °F to 50 °F
±(1.0 % rdg + 6 °F) 50 °F to 400 °F
±(3.0 % rdg + 4 °F) 400 °F to 1832 °F
1000 V dc or 750 V ac rms
4k, 40k, 400k, 1MHz
1 Hz
±(0.1 % rdg + 3 dgts)
10 Hz to 1 MHz: >2.5 V ac rms;
> 1 μs
> 30 % and < 70 %
1000 V dc or 750 V ac rms
0 to 90 %
0.1 %
>10 μs
40 Hz to 20 kHz
(5V logic ) ±(2.0% rdg + 5 dgts)
1000 V dc or 750 V ac rms
