4. Clean dirt and debris from all parts.
5. Align the spool tabs with the tab openings in the base of
the spool.
6. Push the spool cover until it clicks into position.
5.4

INSTALL THE CUTTING LINE

Figure 12 - 15.
Do not put more than 15 feet of cutting line in at a time.
1. Line up the slots on the spool cap with the slots on the
trimmer head.
2. Put the cutting line through the hole. Push the cutting line
until it exits the opposite hole.
3. Pull the cutting line through until there is an equal
quantity of cutting line on each side.
4. Turn the spool cap clock-wise to wind the cutting line
into the trimmer head. Keep approximately 5 in of cutting
line above out of each side of the trimmer head.
5.5

REMOVE THE TRIMMER HEAD

Figure 16.
1. Put the metal rod in the specified angle transmission hole
to fix the trimmer head.
2. Remove the spool cover and the spool.
3. Loosen the nut on the trimmer head clockwise with a
wrench.
4. Remove the trimmer head.
5.6

ASSEMBLE THE TRIMMER HEAD

Figure 17.
1. Put the trimmer head onto the housing.
2. Install the nut.
3. Put the metal rod in the specified angle transmission hole
to fix the trimmer head.
4. Tighten the nut on the trimmer head counterclockwise
with a wrench.
IMPORTANT
You must install the cut-off blade when you use the trimmer
head.
5.7

ASSEMBLE THE BRUSH CUTTER

Figure 18.
WARNING
Wear gloves and be careful with sharp edges.
NOTE
English
Apply the guard to the blade.
Use the specified Nylon locknut which is packed with the
blade to assemble the blade. You must change the locknut
after using it for 20 times.
1. Put the the metal rod in the specified angle transmission
hole to fix the trimmer head.
2. Put the brush-cutter blade on top of the gear box. Make
sure the blade is in the center.
3. Put the plate onto the blade.
4. Put the outer cup above the plate.
5. Put the locknut above the outer cup.
6. Tighten the lock-nut counter-clockwise with the wrench.
5.8

REMOVE THE BRUSH CUTTER

Figure 19.
Apply the guard to the blade.
1. Put the metal rod in the specified angle transmission hole
to fix the trimmer head.
2. Loosen the nut clockwise and remove the outer cup.
3. Remove the plate and brush-cutter blade.
6 TRANSPORTATION AND
STORAGE
6.1

MOVE THE MACHINE

When you move the machine, you must:
• Wear gloves.
• Stop the machine.
• Remove the battery pack and charge it.
• Assemble the blade guard.
6.2

STORE THE MACHINE

• Remove the battery pack from the machine.
• Make sure that children cannot access the machine.
• Keep the machine away from corrosive agents such as
garden chemicals and de-icing salts.
• Secure the machine during transportion to prevent
damage or injury. Clean and examine the machine for any
damage.
