I
H
ATTENTION!
Check before each use
• the product for damage! This significantly reduces the risk of accidents.
• the area below and above the LED modules for free air flow!
Bring the strain relief into the correct position before installing the inter-
changeable bolt.
12

Controls

[a] Supply line BASIC
A
[b] Supply line SWITCH
B
[c] Supply line DIM
D
F
(A) Ring nut
(B) Star grip
(C) Push button (supply line SWITCH)
(D) Potentiometer (supply line DIM)
(E) Push button (supply line DIM)
B
(F) Carry handle
G
(G) Bolt receiver
(H) Quick release
(I) Diffuser

Before initial operation

Strain relief

C
E
