Other materials can be grooved – see tables in appendix.
Other groove and drive shaft sets are required for other
sizes and copper tubing.
A two-stage hydraulic hand pump is used to advance the
groove roll into the pipe to form grooves. An adjustment
nut is included to control groove diameter.
An adjustable stabilizer is provided to aid in maintaining
tracking and control of the pipe during grooving, espe-
cially pipe lengths approaching the 8" minimum pipe
length.
Transmission
Cover
Guard
Hydraulic Pump
Pump Handle
Pump Release
Lever
ON/OFF Switch
Wheels
Warning Label
Foot Switch
Figure 1A – 918-I Roll Groover
Depth Adjustment Nut
Groove Roll
Spindle Lock
Figure 1B – 918-I Roll Groover
999-998-676.10_REV. D

Specifications

Materials,
Pipe ...................Steel, Stainless Steel, Aluminum, Cop-
Capacity
Standard Groove
Roll Sets ............2"-6" schedule 10 and 40 steel pipe
Optional Groove
Roll sets .............8"-12" schedule 10 and 8" Schedule
Pipe Rotation
Label
Crank Handle
Stabilizer
Depth
Stabilizer Wheel
Adjustment ........Depth Adjustment Nut
Actuation ...........2 Stage Hydraulic Hand Pump
Drive Roll
Stabilizer ............Manually adjusted, for 2½" to 12" Pipe
Warning Label
Motor
Type ...................Universal
Stand
Volts (V) .............120
Frequency (Hz) .50/60
Tool Tray
Current (A) ........12.0
Power (W) .........1400
Bolt Down
Controls .............Rotary Type ON/OFF Switch and ON/
Stand .................918-I Stand
Stand Handle
Stand Mounting
Height ................34" (865mm) 27 .4" (696 mm)
Weight
(with Stand) .......185 lbs. (84.1 kg)
Dimensions w/Pump in working position:
Serial
Number
Plate
Base Plate
Sound Pressure
(L
Sound Power
(L
* Sound measurements are measured in accordance with a standardized test per
- S ound emissions may vary due to your location and specific use of these tools.
918-I Roll Groover
per and PVC
40# steel pipe
1" schedule 10 and 40 steel pipe
1¼" to 1½" schedule 10 and 40 steel
pipe
2" - 6" Copper Tube
(Type K, L, M, & DWV)
Refer to the Table I, II and III for other
materials and wall thicknesses
OFF Foot switch
With Stand
(WxDxH)..........39" x 35" x 51.3"
(990 mm x 889 mm x 1303 mm)
With Low Stand
(WxDxH)..........39" x 35" x 44.3"
(990 mm x 889 mm x 1125 mm)
)* ..................92.9 dB(A), K=3
PA
)* .................105.7 dB(A), K=3
WA
Standard EN 62841-1.
220-240
50/60
6.0
1400
918-I Low Stand
