Manual - MODSTER MDX PRO BF 109
Gyro switch
ATTENTION: It is strongly recommended to select position 2 or 1 for the first flight.
As you gain experience, you can progress from 2 to 1 to 0.
The position of the Gyro switch can be changed during the flight. So if you are having difficulty, we
recommend that you set the switch to position 2.
Note that the calibration of the Gyro system, MUST be performed before the very first flight of the
model.
Instructions: Binding receiver and transmitter
Your model is shipped with the transmitter already bound to the receiver.
When binding, the receiver is programmed to recognize the GUID code (Globally Unique ldentifier
code) of a single specific transmitter. When a receiver is bound to a transmitter, it will only respond to
that specific transmitter. If for some reason you need to rebind, please follow these steps:
1. Keep the transmitter switch in the OFF position and the throttle lever in the lowest position.
NOTE: Keep the gyro switch in the middle or beginner position. Keep the aircraft in a quiet
environment to calculate the gyro.
2. Connect the battery to the aircraft and power on the transmitter within 5 sec.
3. The receiver LED will blink for 3-8 sec to bind automatically.
4. When the receiver LED stops flashing, the binding process is complete.
Follow the steps below if you are operating an aircraft that is already bound:
1. First turn on the transmitter.
2. Connect the battery to the aircraft within 3 seconds.
3. The receiver LED in the aircraft will flash and then light up after a few seconds.
4. Set the top gyro control stick to MIDD or BEGINNER
NOTE: When you switch on the Gyro for the first time, let the aircraft stand still for 3-5 sec. in a quiet
environment to calibrate and activate the Gyro. When it starts to respond, it is activated.
5. Turn the throttle stick to maximum and then to minimum to activate the engine.
F
24
0 - Away from you / Gyro off (EXPERT)
1 - Softer in the middle / Gyro helps (ADVANCED)
2 - Towards you / Gyro helps strongly (BEGINNER)
This aircraft is equipped with a pre-installed Gyro system to
make flying easier. The system provides 3 levels of assistance.
When the switch is in position 0 (away from you), there is no
assistance. We recommend this position only to experienced
pilots or experts.
Position 1 (middle switch position) provides gentle leveling and
position 2 "Beginner" provides the strongest support.
