Manual - MODSTER MDX PRO BF 109
Re-observe the aileron to make sure it is properly centered, see here:
If the rudder is tilted left or right, please
rotate the pushrod connectors slightly and
make sure the rudder is properly centered.
If the push rods are as illustrated, the correct length can be adjusted by bending the arcuate sections.
F
22
Rudder surface not
0 centered correctly.
1
Rudder surface
centered correctly.
0
1
0
If the elevator tilts left or right, please rotate
the pushrod connectors slightly and make
sure the elevator is properly centered.
